Decoiler with Cross Cut Attachment K1-CW/100AQ
Decoiler K1-CW with core, two steering and two parking castors. Core has five adjustable arms, avoiding marks, dents or scratch marks, when the coil is clamped or decoiled.
Mobile Decoiler K1-CW/100AQ includes decoiling and cross cut attachment K1-100AQ.
Width coil car = 1000 mm
Recommended coil width = up to 800 mm
Carrying capacity up to max. 2000 kg
Max. cutting capacity 1,0 mm steel, 0,5 mm stainless steel
Max. transport (unroll) capacity AQ: 750 kg
Max. coil outside diameter: 800 mm
Characteristics
- decoiler K1-CW with core, two steering and two parking castors
- core has five adjustable arms, avoiding marks, dents or scratch marks, when the coil is clamped or decoiled
- core inside diameter K1-CW/100: Ø 230-510 mm
Technical data
| K1-CW/100AQ | K1-CW/100AQ | K1-CW/125AQ | K1-CW/150AQ | ||
| Item. No. | 91241-2 | 91242-2 | 91245 | ||
| width; ; mm | 1000 | 1250 | 1500 | ||
| pull capacity ±; ; kg | 750 | 750 | 750 | ||
| weight; ; kg | 125 | 160 | 175 | ||
| capacity; ;kg | 2000 | 1500 | 1500 | ||
| Coil width, max.; ;mm | 800 | 1000 | 1250 | ||
| Optional accessories | K1-CW/100AQ | |||
| K1-LAQ mechanical measuring device | 91260 | Quotation | ||
