Cross Cut Roll-Slitter-Shear K1-AGNRS-4
Cross Cut Roll-Slitter-Shear with linear guide for K1-AGN-3 and K1-AGNU-3.
cutting length 1000 mm
weight = 5 kg
This new roller shear can be converted into a profiling head. The corresponding rollers can be used by the DRÄCO Multibender 200.
to the adapter for the beading rollers
In quotation cart
Technical data
| K1-AGNRS-4 | K1-AGNRS-4 | ||
| Item. No. | 91297-4 | ||
| stainless steel; ; mm | 0,5 | ||
| length; ; mm | 1000 | ||
| aluminium, copper, zinc; ; mm | 1,0 | ||
| weight; ; kg | 5 | ||
